Fourth-generation planar driver
76 × 51 mm transducer with V-Planar and TrueFlow V2.
AMTS acoustic control
Diffusion, waveguides and resonators shape the response.
Nickel-titanium headband
Self-adjusting suspension and carbon-fibre baffles.
Folding and detachable
Compact carry case and removable VIVO cable.
Product details
The Dan Clark Audio EXPANSE is an open-back planar magnetic headphone with a fourth-generation 76 × 51 mm driver. V-Planar diaphragm processing and TrueFlow V2 motor treatment work alongside the Acoustic Metamaterial Tuning System to shape its acoustic response.
Controlled acoustics in an open design
AMTS sits between the driver and ear, combining diffusion structures, waveguides, quarter-wave resonators and Helmholtz resonators. These elements manage high-frequency standing waves and response peaks. The open ear-cup structure allows sound to radiate through the exterior grille.
Light construction and a portable form
A nickel-titanium headband works with a self-adjusting suspension strap, while carbon-fibre baffles keep the driver assembly light and rigid. Synthetic suede and leather ear pads support the fit. Folding gimbals allow EXPANSE to pack into its carrying case, and the supplied detachable VIVO cable is offered in different terminations. Each headphone is hand-built in San Diego, California.
Specifications
- Design
- Open-back planar magnetic headphones
- Driver
- 76 × 51 mm single-ended planar magnetic; fourth generation
- Diaphragm processing
- V-Planar
- Motor treatment
- TrueFlow V2
- Acoustic tuning
- AMTS; waveguides, diffusion and resonators
- Impedance
- 26 Ω
- Sensitivity
- Approximately 90 dB/mW
- Driver matching
- 0.25 dB weighted, 20 Hz–10 kHz
- Headband
- Nickel-titanium; self-adjusting suspension
- Baffle
- Carbon fibre
- Ear pads
- Synthetic suede and leather
- Cable
- Detachable VIVO; termination options vary
- Portability
- Folding gimbals
- Included
- Carrying case; VIVO cable; certificate of authenticity; manual
- Manufacture
- Hand-built in San Diego, California
Dimensions
- Weight
- 418 g
