By WiiM

Amp

Streaming amplifier

Now $439.00Was $549.00

Finish — Space Gray

Model

In-store demo

Available

Stock availability

Available

  • 60 W per channel into 8 Ω

    Class D amplification; 120 W/channel into 4 Ω.

  • Bluetooth in both directions

    Wireless sources and compatible headphones or speakers.

  • HDMI ARC and source inputs

    Stereo PCM TV sound, optical, RCA and USB options.

  • RoomFit and equalisation

    Room calibration, EQ and adjustable subwoofer crossover.

Product details

The original WiiM Amp combines a network streamer, stereo amplifier and television audio connection in a compact aluminium enclosure. Its Class D power stage supplies 60 watts per channel into eight ohms or 120 watts into four ohms, allowing a pair of passive speakers to form a complete streaming system.

Sources and streaming

Wi-Fi and Ethernet connect the WiiM Home app, online services and network libraries. AirPlay 2, Google Cast, Spotify Connect and Tidal Connect provide additional playback options, alongside two-way Bluetooth. HDMI ARC accepts stereo PCM television sound, with optical, analogue RCA and USB connections for other sources. Dolby and DTS bitstreams require conversion to a supported stereo format at the source.

System adjustment and installation

RoomFit calibration, graphic and parametric equalisation and an adjustable subwoofer crossover help match playback to the room and speakers. An ESS DAC feeds the TI TPA3255 amplifier platform. USB storage playback and compatible USB audio output add further system options. Space Gray and Silver finishes share the same original Amp chassis, with a supplied voice remote for everyday control. The manual lists body dimensions of 190 × 63 × 190 mm and a weight of 1.84 kilograms.

Specifications

Model
Original WiiM Amp; distinct from Amp Pro and Amp Ultra
Amplifier
Class D; TI TPA3255
Rated output
60 W/channel into 8 Ω; 120 W/channel into 4 Ω
DAC
ESS ES9018K2M
Audio resolution
Supported PCM playback up to 24-bit/192 kHz
Signal-to-noise ratio
108 dB; manufacturer system specification
THD+N
0.0025% at 5 W
Network
Dual-band Wi-Fi 5; 10/100 Ethernet
Bluetooth
5.0; transmission and reception per current user manual
TV input
HDMI ARC; stereo PCM
Other inputs
Optical Toslink; stereo RCA line input; USB storage
Analogue input
2 Vrms; 24-bit/192 kHz ADC
USB audio output
Compatible USB Audio Class 2.0 devices; up to 24-bit/192 kHz
Speaker outputs
Stereo binding posts for passive speakers
Subwoofer output
RCA; 2 Vrms; adjustable crossover 30–250 Hz
Room adjustment
RoomFit; 10-band graphic and parametric EQ
Streaming integrations
AirPlay 2; Google Cast; Alexa Cast; DLNA; Roon Ready
Connect services
Spotify Connect; Tidal Connect; supported WiiM Home services
HDMI / optical formats
Stereo PCM; no native Dolby/DTS bitstream decoding
Included
Voice remote; HDMI, optical, RCA and mains cables
Finishes
Space Gray; Silver

Dimensions

Body dimensions (W × H × D)
190 × 63 × 190 mm; user-manual body measurement
Net weight
1.84 kg
