- Amplification
- 9 channels, Class G
- Maximum processing channels
- 16
- Matrix channel assignment
- All channels reassignable; subwoofers on channels 4 and 11–16 only
- Power into 8 Ω, 2 channels driven
- 145 W per channel, 20 Hz–20 kHz, 0.5% THD
- Power into 4 Ω, 2 channels driven
- 200 W per channel, 1 kHz, 0.5% THD
- Power into 8 Ω, 7 / 9 channels driven
- 110 / 95 W per channel, 1 kHz, 0.5% THD
- Power into 4 Ω, 7 / 9 channels driven
- 130 / 110 W per channel, 1 kHz, 0.5% THD
- Harmonic distortion
- 0.004% at 80% power, 8 Ω, 1 kHz
- Surround formats
- Dolby Atmos, Dolby TrueHD, DTS:X, DTS-HD Master Audio, IMAX Enhanced, AURO-3D / AURO-2D and MPEG-H
- Room correction
- Dirac Live; optional Dirac Live Bass Control and Active Room Treatment upgrades
- HDMI inputs / outputs
- 7 inputs; 2 Zone 1 outputs and 1 Zone 2 output
- HDMI / HDCP
- 2.1a / 2.3
- Video resolution
- Up to 8K/60 Hz or 4K/120 Hz
- HDR support
- HDR, HDR10, HDR10+, HDR10+ Gaming, Dolby Vision and HLG
- HDMI features
- VRR, ALLM, CEC, eARC/ARC on Zone 1 output 1; on-screen display
- Digital audio inputs
- 2 coaxial RCA and 2 optical Toslink
- Digital audio resolution
- Coaxial up to 24-bit / 192 kHz; optical up to 24-bit / 96 kHz
- Analogue inputs
- 3 stereo RCA pairs
- Preamplifier outputs
- 16 RCA; 2 V RMS per channel
- Signal-to-noise ratio
- 100 dB A-weighted (analogue and digital inputs, reference 50 W)
- Network playback
- Spotify Connect, TIDAL Connect, Qobuz Connect, Roon Ready, AirPlay, Google Cast, Internet Radio, Podcasts and UPnP
- Media formats
- FLAC, WAV, AAC, ALAC, AIFF, MP3 and OGG; gapless playback
- Network audio resolution
- Up to 24-bit / 192 kHz
- Bluetooth
- 5.4; Snapdragon Sound, AAC, LE Audio and Auracast
- Wi-Fi
- IEEE 802.11 a/b/g/n/ac; 2.4 GHz / 5 GHz
- Display
- 6.5-inch colour
- Control
- Radia AV Control app and backlit Bluetooth remote
- Mains supply
- 100–120 V or 220–240 V, 50–60 Hz (regional version)
- Maximum power consumption
- 900 W
- Idle power consumption
- 93 W
- Standby consumption
- 2 W default; 0.4 W low-power
- Supplied accessories
- Regional power cord(s), rear panel cowl, remote and 2 AAA batteries, measurement microphone, 5 m USB cable, Quick Start Guide and safety instructions
